GE FANUC IC693MDL231 Typical Scan Rate Of 0.22 Ms Per 1K Of Logic
Technical Specifications for IC693MDL231
Brand GE Fanuc
Series Series 90-30
Part Number IC693MDL231
Brand GE Intelligent Platforms/GE Fanuc
Product Type Isolated Input Module
Voltage 240 V AC
Inputs 8
Frequency 50/60 Hz
Input Current at a Rated Voltage 15 mA
Isolation between field side and logic side 1500 V RMS
AC Power Yes
DC Power No
LED Indicators 8
About IC693MDL231
The IC693MDL231 isolated input module is a product of the GE
Intelligent Platforms/GE Fanuc. It belongs to the Series 90-30
product line and it operates on a voltage of 240 Volts AC. This
module is well-matched with the GE Series 90-30 PLCs. This
input module comprises 8 isolated input points, with each point
having a single power input terminal. It has input properties
that make it best for use with different input devices which can be
operated with the IC693MDL231 module due to its input
features. These devices include electronic proximity switches,
limit switches, and pushbuttons which can be operated when
the users supply an external source of power. This input module
does not use DC power because it is an AC module.
The GE Fanuc IC693MDL231 input module, like many other Series 90-30
modules, features an LED block located on the top of
this device. This module comes with 8 LEDs in a single row that
show the "ON" and "OFF" status for input points 1 to 8. It also
has a door panel on the front that allows for an insert between the
interior and exterior surfaces. The outer surface of the insert
records the information on circuit identification whenever the door
closes. Additionally, there will be circuit wiring information
on the interior surface of the insert. The insert comes with a red
edge, which indicates that the IC693MDL231 module is a
high-voltage device. The operators of this module have the ability
to install an input module in any of the 5-slot or 10-slot
baseplates of the Series 90-30 PLC by using the input and output
slots.
